Timing Belt and Cover for 2003 Dodge Ram 1500

Timing Belt Cover

Includes Items 2,3,4,5,,11

Plug

.375-18X.475. Oil Gallery In In Cylinder Head Valley

O Ring

Also Serviced With Cover

With Gasket. Includes Pulley.

Hex Flange Head Screw

M14x2.00x80.00. M10x1.50x45.00. Timing Chain Cover And Water Pump To Engine Block

With Seal. 195 Degrees. Thermostat and gasket.

Hex Flange Head Screw

M10X1.50X87.00. Chain Case Cover And Water Pump To Cylinder Block

Hex Flange Head Screw

M14x2.00x80.00. M10x1.50x65.00. Timing Chain Cover And Water Pump To Engine Block

Primary. Also Serviced In Package Item 1

Includes Shaft, Gear, Pin, Bolt, Plate

Hex Screw And Washer

M12X1.75X35.00. Camshaft Sprocket To Camshaft

Hex Head Bolt

M8x1.25x37.50. Chain Guide And Secondary Tensioner To Cylinder Block

Chain Tensioner, Secondary, Right

Secondary

Camshaft Sprocket, Left

Left

Screw

[M8X1.25X57.0]. Chain Guide Right

Driver

Hex Screw And Washer

M10X1.50X110.00. Idler Sprocket To Cylinder Block
